Conservation agriculture for wine and fruit growing

Conservation agriculture is a different way of thinking. Instead of tilling the soil between rows, it remains permanently covered with diverse plant mixtures. Be it to control pests in an ecological way, control soil erosion, increase pollination rates, improve soil fertility – or all at the same time. The benefits of catch crops are well known. But how can you establish them in your alleys? And how can you reliably sow the next catch crops into the green mass? The T-ForcePlus 150 is the perfect companion: you can rely on the proven T-SlotPlus openers and use up to four hoppers to create even the most “exotic” catch crop cocktails.

Details T-ForcePlus 150

1,12 - 2 m

Working width

16.67 \ 18.75 \ 25 cm

Row spacing

> 70 HP

Tractor power

550 l / 180 l

Volume main hopper

All technical details are also available as a PDF

T-ForcePlus 150
Dimensions
Working width 1.12 - 2 m
Transport width 1.2 - 2 m
Length incl. drawbar 4.7 m
Transport height 2.55 m
Unladen weight 1.8 - 3.2 t
Optionales Zusatzgewicht opt. 300kg – 800 kg
max. laden weight 4 t
Openers
Row spacing 16.67 \ 18.75 \ 25
Number of openers max. 8
recommended power > 70 HP
Coulter pressure Is adjusted on each openers by a hydraulic cylinder, from 100 to 500 kg
Cutting disks Hardened notched disks 575 × 5 mm or 520 × 5 mm
Openers In pairs, cast iron NiHard optionally with carbide
Press wheels 2 V-shaped Press wheels; semi-pneumatic 410 × 75 mm or 400 × 115 mm
Seeding depth Fully adjustable in a range from 1 - 8 cm
Attachment
Coupling Lower link hitch (Cat. 2 \ 3)
Drawbar -
Metering units
Type Pneumatic system
Drive Hydraulic drive with variable flow control
Seed and fertilizer hoppers
Main double container 550 l \ 180 l
Adjustable partition wall -
Auxiliary bins Optional, up to 2 × 30 l
Empty level sensors 1 capacitive sensor per hopper
Spreader heads front\rear Optional, 2
IntelliRow Optional/td>
Electronics
auto. coulter pressure control auto. Seed depth control, IntelliForcePlus system
Monitor and VRA Optional: ISOBUS control or 7" monitor
Control openers DW control unit or joystick
Seed flow monitoring Optional, fully integrated in the monitor
Axle
Track 1,200 mm
Brake Optional, hydraulic or pneumatic
Standard tires \ Tracks 420 \ 65 R20
Hydraulics
Connections At least 2 connections + Free return
Oil cooler \ Air heater -
Hydraulic power requirement > 20 l / min
